Modator

Magewell Modator

The Modator family brings the reliability and low-latency performance of the Magewell’s standalone encoders and decoders to a high-density, modular, rackmount form factor. The Modator 2U chassis fits standard rack deployments and supports up to 10 Modator modules.

Designed for 24/7 Operation

Featuring dual power supplies and optimized heat dissipation for 24/7 operation, Modator 2U is well-suited to use cases with high reliability requirements.

Independent Encoding & Decoding

Each installed module can work independently to convert high-quality video and audio signals to and from IP streams.

LED Touch Screen

Through the LED touch screen, users can turn the chassis on or off; view the status of the chassis and each installed module; and configure network settings.

Mix-and-match your choice of Modator modules

Accessory

accessory modator cable modator screw

USB Type A to Type C Cable x1

Part number: ACC00068

Power Cord x2

Part number: ELE00039/ELE00040/ ELE00041/ELE00042/ELE00043

Installation Screws x4

Part number: MEC00048

Pro Convert for NDI® to AIO Module

Modator - pro convert

Pro Convert for NDI® to HDMI Module

Pro Convert HDMI 4K Plus Module

Pro Convert HDMI Plus Module

Modator - pro convert
Specifications and Features

Interfaces

  • 10* Modator slots supporting hot swap of Magewell modules
  • 1* RJ45 1000Mbps Ethernet port
  • 1* USB Type-C port for configuration

Power and Power Consumption

  • Hot-swappable dual power supply
  • AC: 100-240V, 7-3.5A, 60/50Hz
  • Maximum power consumption of the chassis: 200W
  • Maximum power consumption of each slot: 20W
  • Different power cords: ELE00039 (US), ELE00040 (UK), ELE00041 (EU, KR), ELE00042 (AU), ELE00043 (JP)

Others

  • Touchscreen dimension: 91mm x 81mm
  • Browser-based web user interface for the chassis and modules information
  • HTTP-based APIs for custom integration
  • 1-year warranty
  • Form factor: 482mm (L) x 275mm (W) x 88mm (H)
