sdi to usb
Showing 1–10 of 43 results
-
![]()
MORE INFOPro Convert SDI Plus
Magewell Pro Convert SDI encodes to an NDI stream; one SDI input and one SDI loop-through output with eight channels of embedded audio, and it supports SDI input up to DCI 2K 2048 x 1080 video at 60 fps..
- Supports up to 2048×1080 60fps input signals
- One SDI input, one SDI loop-through output with embedded audio.
- Connects existing source equipment into NDI-enabled, IP-based media networks
- Convert one SDI signal with 16 channels of embedded mono audio to an NDI stream.
- Supports up to 8-bit 4:2:2 DCI 2K 2048 x 1080 video at 60 fps encoded NDI output.
- USB 2.0 Type-B 5V power and PoE via RJ45 port.
Magewell 64040 US; 64042 EU; 64043 UK;
64044 AU; 64045 KR; 64046 JPThe device is supplied with different options of power adapters.
SKU: 640400000 (for US/EU/UK/AU/JP users);
-
![Magewell Pro Convert HDMI TX]()
MORE INFOPro Convert SDI TX
Magewell Pro Convert SDI TX 1-Channel NDI Encoder allows you to convert an SDI signal with embedded audio to an NDI stream. It supports resolutions up to 2048 x 1080 at 60p on both input and NDI output. The device can be powered via an included power adapter or over PoE using the NDI port.
- Supports up to 2048×1080 60fps input signals
- Connects existing source equipment into NDI-enabled, IP-based media networks
- Plug-and-play ease of use with automatic input format detection and DHCP network configuration
- Support for encoding videos and embedded audio.
- Support for PoE (Power over Ethernet).
- Support for connection and management of PTZ camera.
- Support for web-based UI remote control.
Magewell PN: 64060 US; 64062 EU; 64063 UK;
64064 AU; 64065 KR; 64066 JPThe device is supplied with different options of power adapters.
SKU: 640600000 (for US/EU/UK/AU/JP users);
-
![Pro Convert 12G SDI Plus]()
MORE INFOPro Convert 12G SDI 4K Plus
Magewell Pro Convert 12G SDI Plus encoder is plug -and-play, converts 4K/60fps, 12G-SDI input signals into full-bandwidth NDI ® streams with low latency.
- Connects existing source equipment into NDI-enabled, IP-based media networks
- Supports inputs up to 4K at 60fps with 16 channels of embedded audio
- Plug-and-play ease of use with automatic input format detection and DHCP network configuration
- SDI loop-through connection
Magewell PN: 640900000 (for US/EU/UK/AU/JP users);
640900002 KRThe device is supplied with different options of power adapters.
-
![]()
MORE INFOPro Convert SDI 4K Plus
Magewell Pro Convert SDI 4K Plus encoder converts SDI input signals up to 4K Ultra HD into full-bandwidth NDI streams with extremely low latency, enabling users to effortlessly connect SDI-equipped sources to NDI-enabled media networks, devices and applications.
- Convert one channel of SD/3G/2K/6G-SDI signal with embedded audio to NDI® stream
- Loop-through one channel of SD/3G/2K/6G-SDI signal with embedded audio
- 1 x RJ45 + PoE NDI Output.
- 6G/3G/HD/SD-SDI Supported.
- Input up to DCI 4K30 10-Bit 4:2:2 Video.
Magewell PN: 64030 US; 64032 EU; 64033 UK;
64034 AU; 64035 KR; 64036 JPThe device is supplied with different options of power adapters.
-
![Magewell Pro Convert HDMI TX]()
MORE INFOPro Convert HDMI TX
Magewell Pro Convert HDMI TX NDI Encoder allows you to convert an HDMI signal with embedded audio to an NDI stream. It supports resolutions up to 2048 x 1200 at 60p on both input and NDI output. The device can be powered via an included power adapter or over PoE using the NDI port
- Supports up to 2048×1200 60fps input signals
- Connects existing source equipment into NDI-enabled, IP-based media networks
- Plug-and-play ease of use with automatic input format detection and DHCP network configuration
- Support for encoding videos and embedded audio.
- Support for PoE (Power over Ethernet).
- Support for connection and management of PTZ camera.
- Support for web-based UI remote control.
Magewell PN: 64050 US; 64052 EU; 64053 UK;
64054 AU; 64055 KR; 64056 JPThe device is supplied with different options of power adapters.
SKU: 640500000 (for US/EU/UK/AU/JP users);
-
![]()
MORE INFOPro Convert HDMI Plus
Magewell Pro Convert HDMI Plus HDMI to NDI one-channel HD signal converter can convert one channel of HDMI signal with embedded audio to NDI® stream.
- Supports up to 4096×2160 60fps (4:2:0) or 30fps (4:4:4), down-converting them to HD NDI
- Connects existing source equipment into NDI-enabled, IP-based media networks
- Plug-and-play ease of use with automatic input format detection and DHCP network configuration
- Convert one channel of HDMI signal with embedded audio to NDI® stream
- Loop-through one channel of HDMI signal with embedded audio
- Convert 4K HDMI Video to NDI Stream
- 1 x HDMI Input, 1 x HDMI Loop-Through
- 1 x RJ45 + PoE NDI Output
- HDMI 1.4, 2.0, DVI-D 1.0
Magewell PN: 64020 US; 64022 EU; 64023 UK;
64024 AU; 64025 KR; 64026 JPThe device is supplied with different options of power adapters.
SKU: 640200000 (for US/EU/UK/AU/JP users);
-
![]()
MORE INFOPro Convert H.26x to HDMI
Magewell Pro Convert H.26x to HDMI decodes a standard H.264 (AVC) or H.265 (HEVC) compressed video stream into a high-quality HDMI output
- Converts an internet-delivered H.264/H.265 stream into a high-quality HDMI output with extremely low latency
- Connects baseband presentation or distribution equipment such as displays, projectors and routers into streaming workflows
- Supports streaming protocols including SRT, RTSP, RTMP, UDP, RTP and HTTP
- Plug-and-play ease of use with automatic output format optimization and DHCP network configuration
- Decodes streams up to 2160×1200 at 60 frames per second
- Up-converts the decoded HD signals to 4K for viewing on Ultra HD displays
Part number:
64130 US; 64132 EU; 64133 UK;
64134 AU; 64135 KR; 64136 JPSKU:
641300000 (for US/EU/UK/AU/JP users); -
![Magewell pro convert ndi to aio]()
MORE INFOPro Convert for NDI to AIO
Magewell Pro Convert for NDI to AIO transforms live, IP-based NDI® streams into high-quality SDI or HDMI outputs for connection to baseband devices such as monitors and projectors, simplifying the use of NDI in applications such as digital signage, video walls and image magnification.
- Convert NDI® stream to HD HDMI and/or 3G SDI signal
- Support SD/HD/FHD standards.
- Support YUV 4:2:2 colour sampling.
- Support up to 48KHz 16bits 8-channel audio streams.
- Support RGB 4:4:4, YUV 4:4:4, YUV 4:2:2 colour sampling.
The device is supplied with different options of power adapters.
Part number:
642100000 (for US/EU/UK/AU/JP users);
642100002 KR -
![]()
MORE INFOPro Convert for NDI to HDMI 4K
Magewell Pro Convert NDI to HDMI 4K is a NDI decoder which supports HDMI output and converts NDI and other multi-protocol IP-based stream into a 4K HDMI signal. Standalone – powered by USB or POE.
- Convert multi-protocol IP-based stream into 4K HDMI signal
- Convert NDI Signal to HDMI 4K Stream
- Embedded Audio Supported
- Up to DCI 4K NDI Input
- Up to 4K60 HDMI Output
Part number:
64110 US; 64112 EU; 64113 UK;
64114 AU; 64115 KR; 64116 JPThe device is supplied with different options of power adapters.
SKU:
641100000 (for US/EU/UK/AU/JP users);
-
![]()
MORE INFOPro Convert HDMI 4K Plus
Magewell Pro Convert HDMI 4K Plus encoder converts HDMI 2.0 signals into full-bandwidth NDI streams with extremely low latency and is truly plug-and play
- Supports up to 4096×2160 60fps (4:4:4) input signals including 1080p 144fps
- One HDMI input, one HDMI loop-through output with embedded audio
- Convert one HDMI signal with 8 channels of embedded audio to an NDI stream
- Connects existing source equipment into NDI-enabled, IP-based media networks
- Plug-and-play ease of use with automatic input format detection and DHCP network configuration
Magewell PN: 64010 US; 64012 EU; 64013 UK; 64014 AU; 64015 KR; 64016 JP
The device is supplied with different options of power adapters.
SKU: 640100000 (for US/EU/UK/AU/JP users);
