Magewell USB Capture AIO

Magewell PN: 32110

One channel HD Capture Device

  • SDI + embedded audio + analog audio
  • HDMI + embedded audio + analog audio
  • DVI + audio
  • VGA + audio
  • Component + audio
  • Composite + audio
  • S-video + audio

Quote Me

Magewell USB Capture AIO  is a 12-bit audio & video capture/playback device that supports USB 3.0, and allows you to capture from various input sources.

Description

Magewell USB Capture AIO is a 12-bit audio & video capture/playback device that supports USB 3.0, and allows you to capture 12-bit HDMI or analog audio. In addition, it supports RGB & YCbCr (YUV) color formats, supports customized EDID, and has integrated cable equalizer supporting cable lengths up to 754′ for HD-SDI signals. The USB 3.0 host interface is directly compatible with various editing applications. Such as VLC,VirtualDub, OBS streaming software, XSplit, vMix, VidBlaster, Wirecast, Microsoft Media Encoder, and Adobe Flash Media Encoder. The USB Capture AIO is compatible with Windows, Linux, Mac & Chrome OS systems.

Magewell’s single-channel USB Capture AIO captures SDI and HDMI both with embedded and analog audio. The USB Capture device extends its functionality to DVI, VGA, Component, Composite and S-video, all plus audio. Magewell’s design philosophy includes a sleek and clean white finish, housing the leading benchmark for portable video capture devices. Features of the Multi-Source USB Capture AIO include: Support for capture resolutions up to 2K (2048×2160) at capture frame rates up to 120 frames per second, allowing for pristine definition, fluidity and with the ability to up/down scale video resolution at will, flexibility..

Magewell USB Capture AIO Connectivity

Magewell usb capture AIO

Multi-Source USB Capture AIO – Features

The Magewell USB Capture AIO supports a deinterlacing algorithm. Converting common analog television signals or 1080i HD sources into non-interlaced form for a smooth, full-sized image. With adjustable brightness, hue and saturation, and various capture colour spaces – clarity is completely within the user’s customization. Aside from being a multipurpose ‘all-in-one’ device, the USB Capture AIO stands out with its mobility. It’s plug and play feature allows the user to transport it anywhere at any time with ease; or if you’re looking for something dedicated, this product will continuously function 24/7.

Compatible with Windows, Linux and Mac OS X, and supporting a driverless interface. The flexibility of this device provides a cost-effective, easy to use, and feature rich solution. Ideal for the users’ who need evolving products.

Short FAQs about USB Capture (Plus)

1. Which software can record 4K videos that are captured by USB Capture HDMI 4K Plus?
Magewell Capture Express, VMix, OBS, XSplit Broadcaster, Meridix Broadcast Producer, etc., support 4K video recording.

2. My computer does not have a USB 3.0 port. How can I use the USB Capture (Plus) device?
It is recommended that you purchase a USB type C to USB 3.0 adapter.

3. Is USB Capture (Plus) compatible with USB 2.0?
Yes. But the limited transmission bandwidth of USB 2.0 cannot guarantee the transmission of
high frame rate or high resolution signal.

4. Can multiple USB Capture (Plus) devices be connected on one computer?
Yes. To ensure that the bandwidth won’t be affected, make sure each USB capture device can be
connected to an independent USB 3.0 Extensible Host Controller. You can check whether your
computer has multiple independent USB 3.0 Host Controllers in Device Management.

5. Do USB Capture (Plus) devices support using a phone or tablet as a source?
Yes. Apple devices can use Lightning to HDMI cables to output screen signals. Android devices
can use MHL adapters to output screen signals.





InterfaceVideo EngineSignal Detection & SupportSoftware Environment
Input Interface
• SDI x1
• DB9 x1
• DVI x1
• Support input resolution up to 2048×2160 pixels

Host Interface
• USB 3.0
8-bit video processing

Deinterlace

Cropping

Color Adjustment

Color Space Conversion

Up/down Conversion

Aspect Ratio Conversion

Mirror and Flip
Auto Detection of Input Signal Format

3D HDMI
OS
• Windows, Linux, Mac, Chrome OS

Driver and Firmware
• Driver Free, Updatable Firmware

Included Software
• USB Capture Utility, Capture Express

Compatible Software
50+

USB Capture Utility V3

USB Capture Utility V3

Utility V3 is a free software for USB Capture and USB Capture Plus devices. Users can easily check and set the capture-related parameters, upgrade the firmware by themselves and export info needed for technical support with the help of the Utility.

Download the Utility for USB Capture Family and for USB Capture Plus Family.



Features Include;

• Capture Format Setting

• Audio Volumn Control

• Mirror and Flip

• EDID Editing and Importing

• Firmware Update

• Export Diagnose Report

For full description, visit the full page; USB Capture Utility V3 Utility V3 also provide functions such as cropping, deinterlacing, device name setting, aspect ratio conversion, timing adjustment, status image setting, etc. For detailed introduction of the settings and functions, please check the Utility V3 User Manual.



Specifications

Supported OSWindows
• Windows 7/8/8.1/10/Server 2008/Server 2008 R2/Server 2012/Server 2016 (x86 & x64)
Linux (support x86, x64 & ARM architecture)
• Ubuntu 12.04/14.04/16.04/17.04/17.10 (x86 & x64)
• CentOS 6.5/7 (x86 & x64)
• Fedora 25/26/27 (x86 & x64)
• Red hat 6.5 and above (x86 & x64)
• Other Linux OS with kernel version 2.6.35 and above
Mac
• OS X 10.9/10.10/10.11
• macOS 10.12/10.13
Chrome OS
Recommended OS (tested)Windows
• Windows 7 Ultimate/8.1 Enterprise/10 Enterprise/Server 2008 R2 DataCenter/Server 2012 R2 DataCenter/Server 2016 R2 DataCenter (x86 & x64)
Linux
• Ubuntu 12.04/14.04/16.04 (x86 & x64)
• Ubuntu 17.04/17.10 (x64)
• CentOS 6.5/7.2 (x86 & x64)
• Fedora 25/26 (x64)
• Red hat 6.5 (x86 & x64)
Mac
• OS X 10.9.5/10.10/10.11.2/10.11.3/10.11.4
• macOS 10.12/10.13.2/10.13.3
Supported APIsWindows
• DirectShow
• Wave API/DirectSound/WASAPI
Linux
• V4L2
• ALSA
OS X/macOS
• QuickTime
• AV Foundation
Supported SoftwareVLC
VirtualDub
OBS
XSplit
vMix
VidBlaster
Wirecast
Microsoft Media Encoder
Adobe Flash Media Encoder
Any other DirectShow, V4L2, QuickTime, AV Foundation based encoding or streaming software
Input InterfacesDVI-I
• DVI 1.0
• HDMI 1.4a (via breakout cable)
• VGA (via DVI-to-VGA convertor)
• Component (via breakout cable)
DB9
• YC (S-Video)
• Composite video
• Analog audio (L+R)
• Component video
BNC
• SD/HD/3G SDI
Host InterfaceUSB 3.0
• compatible with USB 2.0
• compatible with USB 3.1 Gen 1
Input featuresAuto scan of video input sources when there is no signal input to the currently selected input source
Manual selection of video input source
Auto selection of linked (embedded) audio input source when the video input source changes
Manual selection of audio input source
Support for input video resolutions up to 2048x2160
VGA & Component Specific Features12-bit ADC
Support for RGB & YCbCr (YUV) color formats
Support for ‘Seperated sync’, ‘Composite sync’, ‘Sync-on-green’ (SOG), ‘Sync-on-luminance’ (SOY)
Support for DMT, CEA, CVT, GTF video timings
Input signals up to 165MHz pixel rate are digitized with 1:1 sampling
Input signals over 165MHz pixel rate can be digitized with horizontal sub-sampling (resulting in some image quality loss - NOT recommended)
Auto detection of RGB & YCbCr color formats
Auto or manual sampling phase adjustment
Auto horizontal alignment
Support for customized video timings
Support for customized video resolutions for CVT/GTF timings
HDMI Specific Features225MHz HDMI receiver
Adaptive HDMI equalizer support for cables lengths up to 30M
Support for customized EDID
Support for extraction of AVI/Audio/SPD/MS/VS/ACP/ISRC1/ISRC2/Gamut InfoFrames
Full colorimetry support
Support for 8/10/12-bit color depths
Support for RGB 4:4:4, YCbCr 4:4:4, YCbCr 4:2:2 color sampling
Support for up to 2-channel IEC60958 audio streams
Support for extraction of audio formation information & channel status data
Support for extraction of video timing information
Support for extraction of 3D format information
Support for Side-by-Side Half, Top-and-Bottom, Frame Packing 3D mode.
SDI Specific FeaturesIntegrated cable equalizer supporting cable lengths up to 230M for HD-SDI signals
Support for SD/HD/3Ga/3Gb/3Ga-DL/3Gb-DS standards
Support for 2K (2048x1080) mode
Support for RGB 4:4:4, YCbCr 4:4:4, YCbCr 4:2:2 color sampling
Support for 10/12-bit color depth
Support for extraction of SMPTE 352 payload identifier
Support for up to 8 (mono) audio channels at 48KHz
Support for extraction of audio formation information & channel status data
Limited support of 3Gb-DS: only the first stream can be captured
Limited support for capture of the first link of dual link interfaces:
• YCbCr 4:2:2 10-bit 1080p 50/59.94/60: captured as 1080i 50/59.94/60
• YCbCr 4:4:4 10-bit: captured as 4:2:2
• RGB 4:4:4: R/B sub-sampled
YC & Composite Specific Features12-bit ADC
Support for NTSC, PAL, SECAM standards
Auto detection of the standard of input signal
Video Capture formatVideo processing pipelines with 160 Mpixels/s processing bandwidth
Video cropping
Video scaling
Video de-interlacing
• Weave
• Blend top & bottom field
• Top field only
• Bottom field only
Video aspect ratio conversion
• Auto or manual selection of input aspect ratio
• Auto or manual selection of capture aspect ratio
• Three aspect ratio conversion modes: Ignore (Anamorphic), Cropping or Padding (Letterbox or Pillarbox)
Video color format conversion
• Auto or manual selection of input color format & quantization range
• Auto or manual selection of capture color format, quantization range & saturation range
• Support for RGB, YCbCr 601, YCbCr 709 color formats
• Support for Limited or Full quantization range
• Support for Limited, Full & ‘Extended gamut’ saturation range
Video frame rate conversion
Vertical flip and mirror
Multiple devices on one computerSupport for connecting multiple USB devices to one system
Support for setting the device serial number as the device name shown in the system using USB Capture Utility
SDK
The USB Capture SDK provide functions including signal status extraction, capture configuration, etc.
Firmware UpgradeMultiple devices in one system can be upgraded simultaneously
LED IndicatorStatus LEDs indicate the working state of each channel: idle, input signal locked, memory failed or FPGA configuration failed.
Form Factor98mm (L) x 98mm (W) x 25mm (H)
AccessoriesUSB 3.0 cable
DVI to VGA connector
DVI-I to HDMI + Component breakout
DB9 to YC + Composite + Analog Audio + Component breakout
Power Consumption5V max current: ~1 A
max power consumption: ~5 W
Working Environment
Operating temperature: 0 to 45 deg C
Storage temperature: –20 to 70 deg C
Relative Humidity: 5% to 90% non-condensing

Accessories

DVI to VGA connector

Part number: 90011

DB9 to YC + Composite + Analog Audio + Component breakout

Part number: 90020

DVI-I to HDMI + Component breakout

Part number: 90010

USB 3.0 Cable

Part number: 90061

DownLoads

Download: User Manual USB Capture Utility

Download: Tech Specs USB Capture Family

Download: Product Catalogue

Download Software: USB Capture Utility V3

Magewell USB Capture AIO

Magewell USB Capture AIO is utilized in various industries, catering to each one with its unique functionalities. Its adaptability and ability to work seamlessly with a diverse range of software make it an ideal choice for activities such as streaming, web conferencing, lecture recording, live production, medical imaging, and much more.


Plug-and-Play Simplicity and Compatibility

Our USB Capture dongles offer a hassle-free installation process and seamless input detection, ensuring a true plug-and-play experience. With support for Windows, Mac, Linux, and Chrome software, they provide the simplest solution for capturing video and audio signals.

usb capture

USB 3.0 Connectivity for Data & Power

Our USB Capture devices, designed with a single-channel, allow seamless capturing of high-quality video and audio signals on various computer systems, including laptops. These devices utilize a standard USB 3.0 interface, eliminating the need for an external power source. They are perfectly suited for a wide range of applications such as streaming software, web conferencing, lecture capture, live production, medical imaging, and much more.

usb connection

Full Range of Interface Choices

USB Capture dongles are designed to be compatible with a wide range of sources, including professional video cameras, SLR cameras, and hardware switchers. These dongles offer support for various signal types, including analog signals from older equipment. They can handle resolutions ranging from SD (720x480) to 1080p HD (1920x1080).

usb-capture-4

FPGA-based Video Processing

All USB Capture models come with Magewell's FPGA-based video processing technology, which ensures zero-CPU-usage. This advanced technology enables high-quality up/down conversion and image adjustments, while also optimizing CPU availability for third-party software applications.
