6G-SDI 4K to full NDI encoder with loop-through.
Ask us a quick question about this product — signal compatibility, use case fit, or anything technical. We usually reply the same day.
The Pro Convert SDI 4K Plus encodes 6G-SDI 4K30 to full-bandwidth NDI with an active loop-through. It is the bridge for 4K SDI cameras that output single-link 6G-SDI (most current cinema and broadcast cameras) into NDI-based IP production workflows.
Full backward compatibility with 3G, HD and SD-SDI is built in, so the same device can encode 1080p60 from an HD camera in one production and 4K30 from a cinema camera in the next. The loop-through means the SDI signal continues feeding downstream broadcast equipment while NDI encoding runs.
PoE-powered, standalone, configured via web UI or Control Hub. For broadcast 4K NDI workflows it is the standard recommendation; if your cameras output 12G-SDI 4K60 instead of 6G-SDI 4K30, look at the Pro Convert 12G SDI 4K Plus variant.
| SKU | 640300000 |
| Brand | Magewell |
| Category | Pro Convert Encoders |
| Video Input | 1× BNC (SD/HD/3G/6G-SDI) — max input & loop-through: 4096×2160 30fps (6G-SDI) — cable equalizer up to 100m (6G) |
| Loop-through | 1× BNC (SDI loop-through) |
| Audio Input | SDI embedded (up to 8-ch, 48kHz) — 3.5mm analogue line in |
| Network Output | IP network stream (Gigabit Ethernet) |
| Encoding | H.264 / H.265 / SpeedHQ — AAC — up to 4K 30fps encode |
| Streaming Protocols | NDI® High Bandwidth, NDI HX, NDI HX2, NDI HX3 — SRT Caller/Listener — RTMP/RTMPS — RTSP — HLS — TS over UDP/RTP/RIST — HTTP — MPEG-TS |
| Video Processing | De-interlacing — Up/down scaling — Frame rate conversion — Aspect ratio conversion — Colour space conversion (BT.601/709/2020) — PTZ camera control — HDR10 |
| Network & Power | 1× RJ45 Gigabit Ethernet — PoE+ (IEEE 802.3at) powered — Optional USB-C 12V DC |
| Management | Web UI — Magewell Control Hub — REST API — PTZ control (VISCA, PELCO-D/P via NDI) |
| Power | PoE+ (IEEE 802.3at) — Max 12.95W |
| Dimensions | 85mm × 75mm × 26mm — 115g |
| Working Environment | Operating: 0°C to 40°C — Humidity: 20–90% non-condensing |
| UK Stock | In Stock |
| Warranty | 2–3 Years (Magewell manufacturer warranty) |
Full specifications: magewell.com/tech-specs/pro-convert-sdi-4k-plus ↗
Everything included in the box with the Pro Convert SDI 4K Plus. Part numbers and accessory images from official Magewell documentation.




If anything is missing from your delivery, contact us within 7 days and we will arrange a replacement.
Official Magewell documentation for the Pro Convert SDI 4K Plus. Datasheet is mirrored on our server for direct download; drivers, firmware and software live on Magewell's download centre and open in a new tab.
Browse the full Magewell literature library for all product catalogues and datasheets.
No marketing noise. Just new product launches, firmware updates, and the occasional guide.
No spam. Unsubscribe any time. Your email is never shared.
No. The Pro Convert SDI 4K Plus is a standalone converter. It connects to your network and is managed via Web UI. Once configured it operates independently with no host PC required.
The Pro Convert SDI 4K Plus converts its video input to NDI, RTMP, RTSP, SRT.
The Pro Convert SDI 4K Plus accepts 6G-SDI (4K@30fps), 3G/HD/SD-SDI.
Yes. The Pro Convert SDI 4K Plus's network output is compatible with any software that supports its output protocol — including NDI-compatible software such as vMix, OBS (with NDI plugin), Resolume and NewTek products.
Connect your video source and plug the Pro Convert SDI 4K Plus into your network. Access the web interface via its IP address to configure the output stream. Magewell's Device Manager software can also auto-discover devices on your network.
