Magewell ultra stream encoder

Magewell Ultra Stream HDMI

Magewell Ultra Stream HDMI standalone encoder enable users to record or stream high-quality video with one click using on-device buttons or an intuitive smartphone app. Customers can stream live to popular services such as YouTube, Facebook Live and Twitch or to a custom-specified RTMP server, and can simultaneously record video as files to a USB drive or the associated smartphone.

  • HDMI in with an HDMI loop out up to 4k
  • Encodes in HD up to 1080p60 at 8 Mbps
  • Separate 3.5mm microphone in & headphone monitoring jacks
  • Supports two simultaneous streaming destinations
  • Ethernet and WiFi
  • USB port for recording H.264 MP4 files
  • Controlled by Android 5 and up or iOS 9 onwards app with monitoring

Magewell Part Number: Please choose the device which meets your local power supply standard. 53010 US; 53012 EU; 53013 UK


Quote Me

Live streaming to platforms of your choice. Magewell Ultra Stream HDMI is a Single-Channel HD Streaming Encoder that makes live streaming remarkably easy for everyone! Supports up to 4K60p HDMI input and loop-through with real-time down conversion to HD.

Description

Magewell Ultra Stream HDMI

The Ultra Stream HDMI standalone encoder enable users to record or stream high-quality video with one click using on-device buttons or an intuitive smartphone app. Customers can stream live to popular services such as YouTube, Facebook Live and Twitch or to a custom-specified RTMP server, and can simultaneously record video as files to a USB drive or the associated smartphone.

The ultra-compact Magewell Ultra Stream HDMI measures just 4.1 inches (104.6 mm) by 3.7 inches (94.2 mm) with a height of 1.1 inches (28.5 mm), and weighs only 5.1 ounces (143.3g). Like its HDMI-equipped counterpart, Magewell Ultra Stream HDMI offers both wireless and wired network connectivity – with built-in Wi-Fi as well as an RJ-45 Gigabit Ethernet port – in addition to the aforementioned optional mobile broadband modem support. HDMI streaming encoder. Magewell Ultra Stream HDMI Encoder

ultra steam hdmi decoder



Live Stream to Platforms of Your Choice

• Encode and stream at up to 1080p60

• Stream to YouTube, Twitch and Facebook Live with one click

• Stream to a custom RTMP server

. HDMI Stream Encoder



 youtube twitch facebook



phone app

Record High-quality Video for Storage and Sharing

• Preview, record & stream simultaneously

• Record to MP4 files at up to 1080p60

• H.264 video encoding with AAC audio

• Save to mobile phone or to a connected USB flash



Different Formats for Streaming and Recording

• Set different resolutions, frame rates and bit rates for streaming and recording simultaneously. HDMI live stream encoder

Eg. 720p30 for streaming and 1080p60 for recording.

record live



Ultra Stream Support 4K Input & Loop-through

• Supports inputs up to 4096x2160p60 (4:2:0)

• Loop-through at 4K for displays

connections Ultra Stream HDMI



Add your Narration and Monitor your Video Source

  • Add narration through the analog microphone input
  • Monitor the input signal through the analog headphone output

Magewell Ultra Stream HDMI

Ultra Stream Wired & Wireless

The Magewell Ultra Stream HDMI  encoder can be connected to the Internet via Ethernet or Wi-Fi.

icons

One-click Firmware Update

• Check whether a newer firmware version is available.

• Click “update” to start the automatic firmware update.

For more information on the Ultra Stream App, click here…

Magewell Ultra Stream





InterfaceH.264 EncodingSoftware EnvironmentStreaming ServerOthers
Video input Interface
• HDMI x1
• Support up to 4096×2160p60
Loop-through Interface
• HDMI x1
• Support up to 4096×2160p60
USB Interface
• USB 2.0 for USB Flash Drive or USB 3G/4G Modem
Audio Interface
• Headphone Output
• Microphone Input
Network Interface
• Ethernet Interface
Power Interface
• DC+5V
Main Stream
• Up to 1080p60

Sub Stream
• Up to 720p30
Mobile OS
• Android, iOS

Firmware
• Upgradable firmware
Preset
• Youtube Live, Twitch, Facebook Live

Custom
• RTMP
LED Indicators

2-year warranty

Internal SD card

Specifications

Supported Mobile ClientsAndroid
• Android 5.0 and above
iOS
• iOS 9.0 and above
iPhone
• iPhone 5s
• iPhone SE
• iPhone 6 / iPhone 6s / iPhone 6 Plus / iPhone 6s Plus
• iPhone 7 / iPhone 7 Plus
• iPhone 8 / iPhone 8 Plus
• iPhone X
iPod Touch
• iPod Touch 5
• iPod Touch 6
Supported Web Browser
Microsoft Internet Explorer 11
Microsoft Edge
Mozilla Firefox version 61 and above
Google Chrome version 49 and above
Apple Safari 11.1 and above
Opera 55.0.2994.44 and above
Input Interfaces
HDMI
• HDMI 1.4a
3.5mm audio jack
• Microphone interface
Output InterfacesHDMI
• HDMI loop-through
USB
• USB 2.0
3.5mm audio jack
• Headphone interface
Network Interfaces
Wired Ethernet
•10/100/1000Mbps Ethernet

Wi-Fi
•IEEE 802.11 a/b/g/n/ac

USB
•USB 3G/4G Modem (not included)
BluetoothBluetooth 4.0 BLE
HDMI Specific Features
Support for up to 4096x2160 4:4:4/4:2:2 30fps or 4096x2160 4:2:0 60fps input and loopthrough signals
Support for 8/10/12-bit color depths
Support for 60p, 60i, 50p, 50i, 30p, 25p signal formats
Analog Audio Features
Extraction of stereo embedded SDI audio for recording and output via 3.5mm stereo mini-jack Line Out
Recording and streaming analog audio via 3.5 mm microphone interface
Streaming Features
Support for live streaming using RTMP protocol to software including Flash Media Server, Wowza, Red5 and Nginx server
Streaming to Facebook, Twitch and YouTube platforms
Support for streaming to 2 servers simultaneously
Recording Features (to USB Flash Drive)
Support for H.264/HEVC (video) and AAC High Quality (audio) encoding
Supports recording at input signal resolution up to 2048x1080
Support for 1920x1080, 1600x1200, 1440x1080, 1440x900, 1280x1024, 1280x960, 1280x800, 1280x720, 1200x900, 1024x768, 960x540, 800x600, 768x576, 720x576, 720x480, 640x480, 640x360, 480x360 resolutions
Support for 60fps, 50fps, 30fps, 25fps, 24fps, 15fps frame rates
Support for recording as MP4 files
USB Flash Drive file system format: FAT32, NTFS, exFAT, VFAT
Recording Features (to Mobile Device)
Support for recording at up to 1280x720, 30fps
Support for recording as MP4 files
Take still image snapshots during recording
Save recording files and screenshots to system album
Input signal previewing
Timer recording: 15s, 30s, 1min, 2min, 5min
Remote Control Features in App
Remotely control recording and streaming
Remotely check device status by multiple users simultaneously
Support for setting volume, network, recording and live streaming parameters
Support for checking and safely updating device firmware (can also reset to factory firmware version)
Simultaneous main stream and sub stream encoding with customizable parameters
The bitrate for main stream is up to 8 Mbps while for sub stream is 1 Mbps
Support for modifying output AAC bitrate
In-app online help
Support for multiple users log-in simultaneously
Support for device configuration using Web UI
LED Indicator
Indicates the state of the input signal, Ethernet Network, Wi-Fi, USB flash drive
Indicates the working state of the device: startup, recording, streaming, update
Form Factor
94.20mm x 94.20mm x 22.30mm
AccessoriesAC adapter
Power Supply and Consumption
Power port
• 5V/2A
Max power consumption: ~6.0 W

Working Environment
Operating temperature: 0 to 40 deg C
Storage temperature: –20 to 70 deg C
Relative humidity: 5% to 90% non-condensing

Accessories

Power adaptor

(please see part numbers)
