In Stock


Standalone SDI hardware encoder — broadcast SDI to IP without a PC.
Ask us a quick question about this product — signal compatibility, use case fit, or anything technical. We usually reply the same day.
The Ultra Encode SDI is the SDI sister to the Ultra Encode HDMI — a standalone hardware encoder that bridges 3G-SDI sources into IP distribution networks without any host PC. Active SDI loop-through keeps the downstream broadcast chain running while encoding.
For broadcast and live-production facilities migrating from SDI to IP-based delivery, this is the bridge between legacy camera infrastructure and modern streaming workflows. SDI cameras stay in place; the Ultra Encode SDI sits at the camera position or in the equipment rack and encodes the feed for RTMP, RTSP, SRT or NDI|HX distribution.
Common deployments include broadcast venues streaming SDI camera feeds to remote viewing platforms, sports productions streaming to OTT services, and corporate broadcast facilities pushing SDI-based programme output to internal streaming systems.
| SKU | 531200000 |
| Brand | Magewell |
| Category | Ultra Encode |
| Form Factor | Standalone encoder — 135mm × 87mm × 30mm — 310g |
| Video Input | 1× BNC (SD/HD/3G-SDI) — max: 2048×1080 60fps — SD/HD/3Ga/3Gb |
| Loop-through | 1× BNC (SDI loop-through) |
| Audio Input | SDI embedded (up to 8-ch, 24-bit, 48kHz) — 3.5mm line in |
| Audio Output | 3.5mm headphone/line out |
| Encoding | Video: H.264 (AVC), H.265 (HEVC), SpeedHQ — Audio: AAC-LC, AAC-HE, MP3 — Container: MP4, MOV, TS — Dual stream (main + sub) — Up to 32Mbps |
| Streaming Protocols | RTMP/RTMPS — RTSP — SRT Caller/Listener (AES-128/192/256) — NDI® HX2/HX3 — HLS — TS over UDP/RTP — TVU ISSP — RIST Listener — Zixi |
| Destinations / Recording | YouTube, Facebook Live, Twitch, custom RTMP/RTMPS — Up to 6 simultaneous streaming destinations — Record to USB storage — Scheduling |
| Network | 1× RJ45 Gigabit Ethernet — Wi-Fi 802.11 a/b/g/n/ac (Station & AP modes) — Optional 4G/5G USB modem |
| Display / Control | 1.9" LCD (320×172) with real-time preview, audio meter, status — Tap controls |
| Management | Web UI (Chrome/Firefox/Edge/Safari/Opera) — Magewell Control Hub — Zixi ZEN Master — REST API for 3rd party integration |
| Power | 12V DC adapter — Max 18W |
| Dimensions | 135mm × 87mm × 30mm — 310g |
| Working Environment | Operating: 0°C to 45°C — Storage: −20°C to 70°C — Humidity: 5–90% non-condensing |
| UK Stock | In Stock |
| Warranty | 2–3 Years (Magewell manufacturer warranty) |
Full specifications: magewell.com/tech-specs/ultra-encode-sdi ↗
Everything included in the box with the Ultra Encode SDI. Part numbers and accessory images from official Magewell documentation.




If anything is missing from your delivery, contact us within 7 days and we will arrange a replacement.
Official Magewell documentation for the Ultra Encode SDI. Datasheet is mirrored on our server for direct download; drivers, firmware and software live on Magewell's download centre and open in a new tab.
Browse the full Magewell literature library for all product catalogues and datasheets.
No marketing noise. Just new product launches, firmware updates, and the occasional guide.
No spam. Unsubscribe any time. Your email is never shared.
No. The Ultra Encode SDI is a standalone hardware encoder — it requires no PC or host software. It connects to your network and is managed via Web UI / REST API. Simply connect your video source, configure the stream destination once, and it operates independently.
The Ultra Encode SDI supports RTMP, RTMPS, RTSP, SRT, NDI|HX. It can stream simultaneously to multiple destinations.
The Ultra Encode SDI encodes using H.264 + HEVC hardware hardware encoding, delivering low-latency output without putting load on a host CPU.
The Ultra Encode SDI accepts 1x 3G/HD/SD-SDI with loop-through.
The Ultra Encode SDI is configured via Web UI / REST API. Access the web interface by entering the device's IP address in any browser on the same network. No software installation is required.
Yes — the Ultra Encode SDI supports NDI|HX output, allowing it to send video over your network to NDI-compatible receivers.
